Dashboarding With Grafana

Once Prometheus is up and running, Grana can be configured to monitor and visualize Ozone metrics.

Add Prometheus as a data source

In the Grafana web UI, go to Add Data Sources and then select Prometheus.

Enter the Prometheus hostname/port in the HTTP. For example, http://localhost:9094 (verify the port used by looking at Prometheus command line flags -web.listen-address. The port can also be found from Prometheus web UI → Status → Command-Line Flags.)

Choose Prometheus type: Prometheus

Choose Prometheus version: 2.37.x

Finish the setup by clicking on Save and Test.

Import a Grafana dashboard for Ozone

Apache Ozone comes with a default Grafana dashboard. Follow the instructions below to import it:

Download dashboard JSON:

wget https://raw.githubusercontent.com/apache/ozone/master/hadoop-ozone/dist/src/main/compose/common/grafana/dashboards/Ozone%20-%20Overall%20Metrics.json

Open Grafana portal and click on Dashboards on the left and select Import.

Click at Upload JSON file and select the file Ozone - Overall Metrics.json that was just downloaded.

The dashboard is now imported.

Overall dashboard
